Индуктивный датчик Inductive MultiTask sensors, SAM M18 - IMC18-07BPDZC0SA05 - 1061987 (sick150790)

Поставляем Индуктивный датчик Inductive MultiTask sensors, SAM M18 - IMC18-07BPDZC0SA05 - 1061987 для промышленных и гражданских объектов. Оригинальная продукция с гарантией. Подбор аналога, доставка по Москве, СПб и регионам РФ.

есть на складе

Артикул

sick150790

Производитель

Sick

Категория

Индуктивные датчики

наши менеджеры Online

Цена: по запросу

Внимание!

Информация о товаре может быть неполной или требовать уточнения. Мы всегда готовы помочь — свяжитесь с нашими специалистами для получения актуальных данных.

Наши отгрузки

Смотреть ещё

Описание

Описание Inductive MultiTask sensors, SAM M18 - IMC18-07BPDZC0SA05 - 1061987

Features

Design:	Cylindrical
Thread size:	M18 x 1
Sensing range Sn:	7 mm
Assured sensing range Sa:	5.6 mm
Installation type:	Flush
Output type:	PNP
Output function:	NO
Electrical wiring:	DC 4-wire
Enclosure rating:	IP 67 1)
Connection type:	Connector M12, 4-pin
Output Q Imp:	Pulse output (The pulse sequence corresponds to the damping frequency)
Output Q:	Output type (dependant on the adjusted threshold)
Speed range, adjustable via two thresholds:	6...12,000 impulses / min 2)
Acceleration range, adjustable:	0.1...2 impulses / sec? 3)
Time delay, adjustable:	Mode 0: No start-up delay Mode 1: 0...254 sec., adjustable Mode 2: When reaching the upper threshold
footnote	1) According to EN 60529 2) Up to a max. pulse sequence of 12,000 pulses / min 3) Up to a max. pulse sequence of 1.200 pulses / min

Mechanics/electronics

Supply voltage:	10 V DC ... 30 V DC
Ripple:	? 10 %
Voltage drop:	? 2.5 V 1)
Power consumption:	? 35 mA 2)
Hysteresis:	5 % ... 15 % 3)
Repeatability:	? 2 % 4) 5)
Temperature drift (of Sr):	± 10 %
EMC:	According to EN 60947-5-2
Output current Ia:	? 100 mA
Shock and vibration resistance:	30 g, 11 ms/10 Hz ... 55 Hz, 1 mm
Ambient temperature operation:	-25 °C ... +75 °C
Housing material:	Metal, Nickel-plated brass
Housing cap material:	Plastic, PA6
Housing length:	69 mm
Thread length:	52 mm
Tightening torque, max.:	? 40 Nm
Status indicator QImp:	LED, yellow
Status indicator Q:	LED, blau
Minimum response time:	Mode acceleration monitoring 1 sec, Mode speed monitoring 50 ms
Factory setting:	Operating mode: acceleration monitoring, Threshold acceleration: 1 pulse/sec?, Start-up delay mode: time delay, Upper/lower threshold speed: 200/300 pulses/min, Time delay: 5 sec
Fieldbus integration:	IO-Link V1.0
Mode:	COM 2 (38k4)
Cycle time:	5 ms
Process data length:	16 Bit
Process data structure:	1 bit pulse output, 1 bit switching output, 14 bit measured value
footnote	1) At Ia max 2) Without load 3) Of Sn 4) Ub and Ta constant 5) Of Sr

Reduction factors

Note:	The values are reference values which may vary
Carbon steel St37 (Fe):	1
Stainless steel (V2A, 304):	0.8
Copper (Cu):	0.4
Aluminum (Al):	0.45
Brass (Br):	0.4
