Тросиковый датчик расстояния EcoLine EcoLine - BCG05-A1NM0155 - 1068864 (sick152271)

Поставляем Тросиковый датчик расстояния EcoLine EcoLine - BCG05-A1NM0155 - 1068864 для промышленных и гражданских объектов. Оригинальная продукция с гарантией. Подбор аналога, доставка по Москве, СПб и регионам РФ.

есть на складе

Артикул

sick152271

Производитель

Sick

Категория

Тросиковые датчики расстояния EcoLine

наши менеджеры Online

Цена: по запросу

Внимание!

Информация о товаре может быть неполной или требовать уточнения. Мы всегда готовы помочь — свяжитесь с нашими специалистами для получения актуальных данных.

Наши отгрузки

Смотреть ещё

Описание

Описание EcoLine - BCG05-A1NM0155 - 1068864

Performance

Measuring range:	0 m ... 1.25 m
Repeatability:	? 0.2 mm 1)
Linearity:	? ± 2 mm 2)
Hysteresis:	? 0.4 mm 3)
Resolution (wire draw + encoder):	0.02 mm 4) 5)
footnote	1) 2) 3) Value refers to wire draw mechanism 4) 5)

Механические параметры

Mass (including encoder):	200 g
Mass (mechanics):	80 g
Measuring wire diameter:	0.45 mm
Measuring wire material:	Highly flexible stranded steel 1.4401 stainless steel V4A
Housing material, wire draw mechanism:	Plastic, Noryl
Spring return force:	Ca. 1 N ... ca. 1.4 N 1)
Life of wire draw mechanism:	1 million cycles 2)
Actual length of cable extension:	1.45 m
Wire acceleration:	10 m/s?
Operating speed:	4 m/s
Mounted encoder:	AHM36 SSI
Mounted mechanic:	MRA-G055-101D4
Part number mechanic:	5324019
Part number encoder:	1068328
Mass (measuring wire):	0.58 g/m
Length of wire pulled out per revolution:	150 mm
Number of steps per revolution:	8,192
footnote	1) These values were measred at an ambient temperature of 25 °C. There may be variations at other temperatures. 2)

Электрические параметры

Initialization time:	50 ms 1)
Supply voltage:	4.5 V ... 32 V
Code type:	Gray, binary
Power consumption:	1.5 W
MTTFd: mean time to dangerous failure:	270 a 2) 3)
footnote	1) Valid positional data can be read once this time has elapsed. 2) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of components, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no. 8015532. 3) The value applies to the mounted encoder

Interfaces

Electrical interface:	SSI
Electrical connection:	Universal 1)
Clock frequency:	2 MHz
SET (electronic adjustment):	H-active (L = 0 - 3 V, H = 4,0 - Us V)
Interface signals:	Clock +, Clock -, Data +, Data-
Encoder:	Absolute encoders
footnote	1)

Ambient data

EMC:	(according to EN 61000-6-2 and EN 61000-6-3)
Enclosure rating encoder:	IP 66 / IP 67 (according to IEC 60529), housing side, IP 66 / IP 67 (according to IEC 60529), shaft side
Enclosure rating mechanic:	IP 50
Resistance to shocks:	100 g, 6 ms (according to EN 60068-2-27)
Resistance to vibration:	20 g, 10 Hz ... 2,000 Hz (according to EN 60068-2-6)
Relative humidity / Condensation:	90 % (condensation of the optical scanning not permitted)
Working temperature range (encoder):	-30 °C ... +70 °C
Working temperature range (mechanics):	-30 °C ... +70 °C
Working temperature range (combination):	Wird definiert durch den hoheren mininalen und niedrigeren maximalen Wert des Arbeitstemperaturbereichs von Encoder und Mechanik
